| CONTROLLER NAME | Model No & TYPE | WACC-2XXX |
|---|---|---|
| SIZE | Dimention(HxWxD) mm | 96x96, 72x72, 48X48 |
| Panel Cutout (mm) | 92x92, 68x68, 44x44 | |
| DISPLAY | Upper Lower |
7 segment, 4 digit RED LED display 7 segment, 4 digit RED LED display |
| INPUT | Sensor & Range | PT-100 3w 0 To 150°C |
| OUTPUT | Control Output Output Rating |
Heater SSR Valve Relay Alarm Buzzer 1C/O, 2A, 230V AC 24V DC for Buzzer |
| Set Point | Set point for Heater Relay, Purging Temperature Relay Valve open and close time after Tempature achive Hysterisis |
| Operating Mode | PID/ON-OFF |
| Accuracy | ±0.5% of full scale |
| Power Requirement | 100-260V AC, 50Hz |
| Protection | Relay turn off in case of sensor break or fail |
| Indication | "OPEN" message display if sensoor disconnected & alaram on with led indication Pressure display In PSI if enable |
| Memory Backup | Selectable according to requirement |
| Modbus communication | RS-485 Output Optional |
